Recom DC/DC converter series REC5A

DC/DC converter modules in a DIL24 housing with 5W, a continuous short circuit protection and an undervoltage-lockout UVLO (REC5A-_/X1). These devices do not require a minimum load and have an efficiency of up to...

Recom DC/DC converter series REC5A

DC/DC converter modules in a DIL24 housing with 5W, a continuous short circuit protection and an undervoltage-lockout UVLO (REC5A-_/X1). These devices do not require a minimum load and have an efficiency of up to 81% as well as a withstand voltage of 2kV AC. They are suitable for direct PCB mounting and comply with EMI class A without external components as well as UL60950-1, UL62368-1, IEC62368-1, EN62368-1 and EN55032 class B. We offer the following types of this Recom series: REC5A-0505SW/H2, REC5A-2405SW/H2 and REC5A-2405SW/H2/X1.

  • single output
  • output: 5W
  • maximal output voltage tolerance: ±2% (at 100% load)
  • maximal ripple and noise: 50mVpp
  • withstand voltage I/P-O/P: 2000V DC
  • operating temperature: -40 to +68°C
  • weight: 13g
