Mean Well LED driver series HLG-320H-C

LED drivers in a metal housing (IP67) with a 3 in 1 dimming function (0 to 10V DC, 10V PWM, resistor), a long service life (62.000h) and a constant voltage. These devices are protected against overload (auto r...

Mean Well LED driver series HLG-320H-C

LED drivers in a metal housing (IP67) with a 3 in 1 dimming function (0 to 10V DC, 10V PWM, resistor), a long service life (>62.000h) and a constant voltage. These devices are protected against overload (auto recovery), overtemperature, short circuit as well as overvoltage and comply with EN61347-1, EN55015, EN61347-2-13 as well as EN61000-3-2 class C. They are suitable for LED lighting applications and have a built-in active PFC function. We offer the following types of this Mean Well series: HLG-320H-C700B, HLG-320H-C1050B, HLG-320H-C1400B, HLG-320H-C1750B, HLG-320H-C2100B, HLG-320H-C2800B and HLG-320H-C3500B.

single output
output: 299,6 to 320,6W
input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC
maximal input inrush current: 70A
withstand voltage I/P-O/P: 3750V AC
withstand voltage I/P-FG: 2000V AC
withstand voltage O/P-FG: 1500V AC
operating temperature: -40 to +85°C
dimensions: 252x90x43,8mm
weight: 1880g
