Mean Well LED driver series PWM-60

LED drivers in a plastic housing (IP67) with a universal input, 60W and a PWM style output. These devices are protected against overvoltage, short circuit, overload (auto recovery) as well as overtemperature and comply with EN61347-1, EN61347-2-13 as well as EN55015. They have a built-in active PFC function and are suitable for LED lighting applications. We offer the following types of this Mean Well series: PWM-60-12, PWM-60-24, PWM-60-36 and PWM-60-48.

single output
output: 60 to 60,12W
input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC
maximal input inrush current: 50A
no-load power: <0,5W
withstand voltage I/P-O/P: 3750V AC
operating temperature: -40 to +85°C
dimensions: 150x53x35mm
weight: 490g
