Mean Well DIN rail power supply series NDR-120

Switching power supplies with 120W, a universal input and an LED indicator for DC OK. These devices are suitable for DIN rail mounting and are protected against overload (auto recovery), overvoltage as well as short circuit. They have touch-protected screw terminals and comply with UL508, EN61000-6-2, EN50082-2, EN62368-1 as well as EN55032 class B. We offer the following types of this Mean Well series: NDR-120-12, NDR-120-24 and NDR-120-48.

single output
output: 120W
input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC
maximal input inrush current: 35A
leakage current: <1mA
output voltage adjustment: +15%
overload protection: 105 to 130%
withstand voltage I/P-O/P: 3000V AC
withstand voltage I/P-FG: 2000V AC
withstand voltage O/P-FG: 500V AC
operating temperature: -20 to +70°C
weight: 600g
