time switch 16A, 12 by Finder

* series: 12
* for daily or weekly time setting
* by Finder

12.01.8.230.0000, 12.11.8.230.0000:
* mechanical daily time switch
* contact
12.01_: 1 CO (SPDT)
12.11_: 1 NO (SPST-NO)
* time switches for daily time setting
* 12.01_: 30 minutes interval setting
* 12.11_: 15 minutes interval setting
* easily adjustable
* 12.01_: for 35 mm rail (EN 60715) mount (TH35)
* 12.11_: for 17,5 mm rail (EN 60715) mount (TH35)
* power reserve of 100 hours during a power failure
* contact material: AgCdO
* rated current: 16A
* max. switching current: -/30A
* max. switching power: 4000VA
* protection category: IP20
* nominal lamp rating (230V)
incandescent: 2000W
compensated fluorescent: 750W
uncompensated fluorescent: 1000W
halogen: 2000W
* minimum switching load: 1000mW
* accuracy: 1,5s/day
* lifetime, electrical: 50x10³ operations
* operating temperature: -5...+50°C

12.51.8.230.0000
* digital time switch
* contact: 1 CO (SPDT)
* time switches for daily time setting
* 30 minutes interval setting
* easily configurable for daily or weekly programming with joy-stick
* LCD display, with back-light
* internal battery for set-up and programming without supply, easily replaceable from the front
* daylight saving preset
* 6 year power reserve
* protective separation between supply and contacts
* 35 mm rail (EN 60715) mount
* contact material: AgSnO2
* rated current: 16A
* max. switching current: 30A
* max. switching voltage: 400V AC
* max. switching power: 4000VA
* protection category: IP20
* nominal lamp rating (230V)
incandescent: 2000W
compensated fluorescent: 750W
energy saving (CFL, LED): 200W
halogen: 2000W
* minimum switching load: 1000mW
* accuracy: 1s/day
* lifetime, electrical: 100x10³ operations
* operating temperature: -20...+50°C
