• power: 0.1W
• series: PT6, top adjustment
• shaft: arrow slot
• by Piher
• pitch: 5/5mm
• housing: Ø 6mm
• polyester substrate
• sealed enclosure, dust and colophony proof, protected against harmful influences
• double wip...
• power: 0.1W
• series: PT6, top adjustment
• shaft: arrow slot
• by Piher
• pitch: 5/5mm
• housing: Ø 6mm
• polyester substrate
• sealed enclosure, dust and colophony proof, protected against harmful influences
• double wiper, dual support
• excellent stability, multipurpose applications as variable film potentiometer
• wiper positioned at 50% or fully clockwise
• resistant against cleaning agents, ultrasonic cleaning possible
• taper: linear
• power rating (TU = 40°C): 0.1W
• operating voltage, max.: 100V DC
• resistance tolerance ≤1MΩ: ±20%
• resistance tolerance >1MΩ: ±30%
• temperature range: -25...+70°C
• resistance tolerance mechanical: 235 ±5°
• resistance tolerance electrical: 220 ±20°
• torque: 0.2...2Ncm
• stop torque: 4Ncm
• diameter: 6.3mm
• depth: 3.3mm
• resistance and production code
