Mean Well DIN rail power supply series DRH-120

Switching power supplies in a DIN rail housing with 120W, a universal input and screw terminals (touch guard). These devices have a 2-phase input and are protected against overload (auto recovery), ov...

Mean Well DIN rail power supply series DRH-120

Switching power supplies in a DIN rail housing with 120W, a universal input and screw terminals (touch guard). These devices have a 2-phase input and are protected against overload (auto recovery), overtemperature, overvoltage as well as short circuit. They have a fanless design and comply with EN61000-6-2, EN50082-2, EN55032, EN61204-3 class B, EN61000-3-2 as well as EN61000-3-3. We offer the type DRH-120-48 of this Mean Well series.

  • single output
  • output: 120W
  • input voltage: 340 to 550V AC (47 to 63Hz), 480 to 780V DC
  • maximal input inrush current: 50A
  • leakage current: <3,5mA
  • overload protection: 105 to 160%
  • operating temperature: -20 to +60°C
  • dimensions: 65,5x125,2x100mm
  • weight: 750g
> More
Data Sheet
Showing 1 - 1 of 1 product
  • Product Stock Unit price Volume discounts
  • Mean Well
    DRH-120-48
    49,29 €
    32661 DRH-120-48 DRH-120-48
    49,29 €

    More
    Stock: 1
Showing 1 - 1 of 1 product
