Mean Well LED driver series HLG-150H

LED drivers in a metal housing (IP65) with a constant current, the current limitation, 150W as well as a potentiometer for adjusting the output voltage. These SELV compliant devices are protected against overload (auto recovery), overtemperature, overvoltage as well as short circuit and comply with EN61347-1, EN61347-2-13, EN55015, EN61000-3-2 class C, EN61000-3-3 as well as EN61547. They are suitable for LED lighting applications and have a built-in active PFC function. We offer the following types of this Mean Well series: HLG-150H-12A, HLG-150H-15A, HLG-150H-20A, HLG-150H-24A, HLG-150H-30A, HLG-150H-36A, HLG-150H-42A, HLG-150H-48A and HLG-150H-54A.

single output
output: 150 to 153,6W
input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC
maximal input inrush current: 65A
withstand voltage I/P-O/P: 3750V AC
withstand voltage I/P-FG: 2000V AC
withstand voltage O/P-FG: 1500V AC
operating temperature: -40 to +90°C
dimensions: 228x68x38,8mm
weight: 1150g
