Mean Well LED driver HLG-80H-C

LED drivers in a metal housing (IP65) with a constant current, a universal input and 90W. These devices are protected against overload (auto recovery), overvoltage as well as short circuit and comply with EN61000-3-2 class C, EN55015, EN61347-1 as well as EN61347-2-13. They have a built-in active PFC function as well as a built-in potentiometer for adjusting the current limitation and are suitable for LED lighting applications. We offer the following types of this Mean Well series: HLG-80H-C350A and HLG-80H-C700A.

single output
output: 89,95 to 90,3W
input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC
maximal input inrush current: 60A
withstand voltage I/P-O/P: 3750V AC
withstand voltage I/P-FG: 2000V AC
withstand voltage O/P-FG: 1500V AC
operating temperature: -40 to +70°C
dimensions: 195,6x61,5x38,8mm
weight: 840g
