Hahn flat transformers

Flat transformers with 40VA, a two chamber winding (vacuum encapsulated) and a UI 48 core. These transformers have a leakage and sparking distance in air of at least 10mm and are routine-tested with 6000V between primary and...

Hahn flat transformers

Flat transformers with 40VA, a two chamber winding (vacuum encapsulated) and a UI 48 core. These transformers have a leakage and sparking distance in air of at least 10mm and are routine-tested with 6000V between primary and secondary winding. They are suitable for PCB mounting as well as for 115/230V power supplies and comply with EN61558 as well as VDE 0570. We offer the following tyoes of this Hahn series: BV UI 481 0002 and BV UI 481 0003.

  • output: 40VA
  • core: UI 48
  • input voltage: 2x115V
  • not short circuit proof
> More
Data Sheet
