> Passive elements>Fuses>PolySwitch>Littelfuse self-resetting fuses, PTC, radial, 0,05 to 3,75A, RXEF series

Manufacturers

0.05 to 3.75A

• polymer PTC body, small compact size
• resettable switching device
• low current loss due to a low resistance in normal use
• power supplies, motor amplifiers up to a maximum voltage of 60Vrms
• operating voltage, max.
RXEF 005...RXEF ...

0.05 to 3.75A

• polymer PTC body, small compact size
• resettable switching device
• low current loss due to a low resistance in normal use
• power supplies, motor amplifiers up to a maximum voltage of 60Vrms
• operating voltage, max.
RXEF 005...RXEF 017: 60V
RXE F020...RXEF 375: 72V
• interrupting current, max.: 40A
• temperature range: -40...+85°C

dimensions

pitch: 5.08 mm
• RXEF 005: 8.0 x 8.3 mm
• RXEF 010: 7.4 x 11.6 mm
• RXEF 017: 7.4 x 12.7 mm
• RXEF 020: 7.4 x 11.7 mm
• RXEF 025: 7.4 x 12.7 mm
• RXEF 030: 7.4 x 12.7 mm
• RXEF 040: 7.6 x 13.5 mm
• RXEF 050: 7.9 x 13.7 mm
• RXEF 065: 9.4 x 14.5 mm
• RXEF 075: 10.2 x 15 mm
• RXEF 090: 11.2 x 15.8 mm
• RXEF 110: 12.8 x 17.5 mm
• RXEF 135: 14.5 x 19.1 mm
• RXEF 160: 16.3 x 20.8 mm
• RXEF 185: 17.5 x 22.2 mm

pitch: 10.2 mm
• RXEF 250: 20.8 x 25.4 mm
• RXEF 300: 23.9 x 28.6 mm
• RXEF 375: 27.2 x 31.8 mm

> More
--
Showing 1 - 18 of 18 products
Showing 1 - 18 of 18 products
