code switch, SMD version, 1.27mm pitch

• top tape sealed
• pitch: 1.27mm

SD_mini
• can be assembled by any automatic IC inserter
• raised actuator
• bottom epoxy sealed against flux immersion
• switching capacity: 25mA/24V DC
• transmission current: 100m...

code switch, SMD version, 1.27mm pitch

• top tape sealed
• pitch: 1.27mm

SD_mini
• can be assembled by any automatic IC inserter
• raised actuator
• bottom epoxy sealed against flux immersion
• switching capacity: 25mA/24V DC
• transmission current: 100mA/50V DC
• contact resistance, max.: 100mΩ
• insulation resistance (100V DC), min.: 500MΩ
• dielectric strength, min.: 300V DC/1min.
• capacity of adjacent switch, max.: 5pF
• spacing between rows: 8.9mm
• insulation shell: UL94V-0, black
• contact finish: gold over nickel
• operating temperature: -25...+70°C
• operating force, max.: 800g
• switching capacity: 1000 operations
• air humidity: 95% RH, 40°C/96h
• vibration test: 10Hz-55Hz-10Hz/6h
• by ECE

DX62_
• for highest reliability
• switching capacity: 100mA/50V DC
• contact resistance, max.: 100mΩ
• isolation resistance (100V DC), min.: 100MΩ
• capacity of adjacent switch, max.: 5pF
• operating temperature: -20...+80°C
• operating force, max.: 400gf
• by Greatecs
