> Passive elements>Switches/keys>Code switches>ECE DIL switches, SMD, pitch 2,54mm, SD and ESD series

Manufacturers

code switch, SMD version

* pitch: 2.54mm
* can be assembled by any automatic IC inserter
* switching capacity: 25mA/24V DC
* contact resistance, max. new state: 50mΩ
* contact resistance, max. after operating life test: 100mΩ
* dielectric strength, min...

code switch, SMD version

* pitch: 2.54mm
* can be assembled by any automatic IC inserter
* switching capacity: 25mA/24V DC
* contact resistance, max. new state: 50mΩ
* contact resistance, max. after operating life test: 100mΩ
* dielectric strength, min.: 500V DC/1min.
* capacity of adjacent switch, max.: 5pF

SD_/ESD_
* type: SMD IC
* SD_(ESD_EZ): extended actuator
* SD_, ESD_LDZ: low profile actuator
* bottom epoxy sealed against flux immersion
* transmission current: 100mA/50V DC
* insulation resistance (100V DC), min.: 1000MΩ
* spacing between rows: 11.2mm
* insulation shell: UL94V-0, black
* contact finish: gold over nickel
* operating temperature: -25...+70°C
* operating force, max.: 800g
* switching capacity: 2000 operations
* air humidity: 95% RH, 40°C/96h
* vibration test: MIL-STD-202F, method 204D
* by ECE

DX236_
* type: vertical
* isolation resistance (500V DC), min.: 1000MΩ
* temperture range: -40...+85°C
* operating force, max.: 1000gf
* operating life/cycles mechanical: 3.000
* operating life/cycles electrical: 2.000
* by Greatecs
