> Passive elements>Relays>Reed relays>ECE reed relays, DIL housing, 1 normally open contact, EDR series

Manufacturers

reed relays, DIL housing, 1 normally-open

• wash tight
• plug-in a 14-pole DIP/DIL-IC socket (see note)
• configuration: SPST-NO
• switching capacity, max.: 10W
• switching voltage, max.: 100V DC
• switching current, max.: 0.5A
• transport current, max....

reed relays, DIL housing, 1 normally-open

• wash tight
• plug-in a 14-pole DIP/DIL-IC socket (see note)
• configuration: SPST-NO
• switching capacity, max.: 10W
• switching voltage, max.: 100V DC
• switching current, max.: 0.5A
• transport current, max.: 1A
• contact resistance: 150mΩ
• insulation resistance (coil/contacts): 1010Ω
• breakdown voltage, min. (coil/contacts): 1400V DC
• operate time, max. (incl. bounce): 1ms
• release time, max.: 0.5ms
• vibration resistance: 30G
• temperature range: -40...+85°C

> More
--
Showing 1 - 3 of 3 products
