SMD crystal oscillators Io14, IO16 by Red Frequency

* frequency: 4 to 100 MHz
* in metal housing, 5.2x3.4x1.2mm
* consisting of piezoelectric resonator and oscillator circuit
* high reliability due to hermetically sealed metal housing
* tristate
* freq...

SMD crystal oscillators Io14, IO16 by Red Frequency

* frequency: 4 to 100 MHz
* in metal housing, 5.2x3.4x1.2mm
* consisting of piezoelectric resonator and oscillator circuit
* high reliability due to hermetically sealed metal housing
* tristate
* frequency stability (up -20 to +70°C): ±50ppm
* temperature range: up -20 to +70°C

IO14_
* suitable for CMOS
* operating voltage (VDD): 3.3 Volt DC
* maximum current requirement
4 to 25 MHz: 8 mA
40 to 50 MHz: 20 mA
100 MHz: 30 mA

IO16_
* suitable for CMOS/TTL
* operating voltage (VDD): 5 Volt DC
* maximum current requirement
8 MHZ: 10 mA
10 to 18.432 MHz: 15 mA
20 to 25 MHz: 25 mA
40 MHz: 35 mA

> More
Showing 1 - 19 of 19 products
  • Product Stock Unit price Volume discounts
  • Red Frequency
    IO 14 4 MHz
    1,46 €
    43288 IO 14 4 MHz IO14004.000M03.3EB IO14004.000M03.3EB
    1,46 €

    More
    Stock: 0
  • Red Frequency
    IO 14 8 MHz
    0,966 €
    46212 IO 14 8 MHz IO14008.000M03.3EB IO14008.000M03.3EB
    0,966 €

    More
    Stock: 485
  • Red Frequency
    IO 16 8 MHz
    1,09 €
    46217 IO 16 8 MHz IO16008.000M05.0EB IO16008.000M05.0EB
    1,09 €

    More
    Stock: 0
  • Red Frequency
    IO 14 10 MHz
    0,247 €
    43289 IO 14 10 MHz IO14010.000M03.3EB IO14010.000M03.3EB
    0,247 €

    More
    Stock: 0
  • Red Frequency
    IO 16 10 MHz
    0,959 €
    46218 IO 16 10 MHz IO16010.000M05.0EB IO16010.000M05.0EB
    0,959 €

    More
    Stock: 0
  • Red Frequency
    IO 14 11,0592 MHz
    0,238 €
    46213 IO 14 11,0592 MHz IO14011.0592M03.3EB IO14011.0592M03.3EB
    0,238 €

    More
    Stock: 0
  • Red Frequency
    IO 16 11,0592 MHz
    1,22 €
    46219 IO 16 11,0592 MHz IO16011.0592M05.0EB IO16011.0592M05.0EB
    1,22 €

    More
    Stock: 1095
  • Red Frequency
    IO 14 16 MHz
    0,364 €
    43290 IO 14 16 MHz IO14016.000M03.3EB IO14016.000M03.3EB
    0,364 €

    More
    Stock: 0
  • Red Frequency
    IO 14 18,432 MHz
    0,377 €
    46214 IO 14 18,432 MHz IO14018.432M03.3EB IO14018.432M03.3EB
    0,377 €

    More
    Stock: 0
  • Red Frequency
    IO 16 18,432 MHz
    0,954 €
    46220 IO 16 18,432 MHz IO16018.432M05.0EB IO16018.432M05.0EB
    0,954 €

    More
    Stock: 0
  • Red Frequency
    IO 14 20 MHz
    1,01 €
    43291 IO 14 20 MHz IO14020.000M03.3EB IO14020.000M03.3EB
    1,01 €

    More
    Stock: 0
  • Red Frequency
    IO 16 20 MHz
    0,82 €
    46221 IO 16 20 MHz IO16020.000M05.0EB IO16020.000M05.0EB
    0,82 €

    More
    Stock: 3
  • Red Frequency
    IO 14 24 MHz
    1,42 €
    43292 IO 14 24 MHz IO14024.000M03.3EB IO14024.000M03.3EB
    1,42 €

    More
    Stock: 0
  • Red Frequency
    IO 14 25 MHz
    0,728 €
    46215 IO 14 25 MHz IO14025.000M03.3EB IO14025.000M03.3EB
    0,728 €

    More
    Stock: 0
  • Red Frequency
    IO 16 25 MHz
    0,223 €
    46222 IO 16 25 MHz IO16025.000M05.0EB IO16025.000M05.0EB
    0,223 €

    More
    Stock: 0
  • Red Frequency
    IO 14 40 MHz
    1,37 €
    43293 IO 14 40 MHz IO14040.000M03.3EB IO14040.000M03.3EB
    1,37 €

    More
    Stock: 0
  • Red Frequency
    IO 16 40 MHz
    0,247 €
    46223 IO 16 40 MHz IO16040.000M05.0EB IO16040.000M05.0EB
    0,247 €

    More
    Stock: 0
  • Red Frequency
    IO 14 50 MHz
    1,42 €
    43294 IO 14 50 MHz IO14050.000M03.3EB IO14050.000M03.3EB
    1,42 €

    More
    Stock: 0
  • Red Frequency
    IO 14 100 MHz
    1,29 €
    46216 IO 14 100 MHz IO140100.000M03.3EB IO140100.000M03.3EB
    1,29 €

    More
    Stock: 0
Showing 1 - 19 of 19 products
